Compact solar water heating system

Compact solar water heating system

Principle of operation

In this system, the heat collector and the hot water storage tank are integrated, and the hot water storage tank has a built-in electric auxiliary heating device. The temperature of the heat collector is increased by the sun, and the temperature of the water in the heat collector and the hot water storage tank is different to form a density difference, which produces a physical phenomenon of cyclic power, that is, thermosyphon, which promotes the natural flow of hot water between the heat collector and the hot water storage tank. Circulate the flow, and finally heat the water in the hot water storage tank.

The hot water supply adopts falling water supply. The combination of solar energy system and conventional energy (electricity) realizes all-weather hot water supply.

System Features

1.The products are placed on the roof of the building with good lighting effect and high utilization rate of solar energy.

2.The product structure is simple, the technology is mature, and the operation is stable.

3.System accessories are popular and easy to maintain.

4.The product price is low.

5.It can meet the basic needs of users.
